20W-24W Wallmount

Level 6
We provide a comprehensive selection of Level 6 power adapters that are flexible in customization based on clients' demands. Billion's manufacturing factories have been certified with ISO9001 highlighting reliable production and quality controls with a capacity of 400k/month. Contact us today and receive a competitive price quotation - welcome small quantity OEM/ODM customers.

Key Features & Benefits

​​Features
  • BA024 series product
  • Efficiency: DOE/ErP level VI efficiency
  • Over current protection
  • Short circuit protection
  • Class II construction
  • No load power consumption < 0.075W
  • Fixed AC blades：US,UK,EU,AU,CN
  • Case option: right angle / straight type

 Application Diagram

Specifications

Specification
AC input voltage 90V - 264V
DC output voltage 5V - 56V
Output load (max) 0A - 4A
Output regulation ±5%
Efficiency > 86.8% (5V ≥ 83.68%)
MTBF 50000 hrs
EMI & Safety approval UL, cUL, CCC, RCM, CE, FCC, CB, TUV, Level 6
Dimension Right type: 72 (L) x 34 (W) x 51.5 (H)mm / Straight type: 80 (L) x 52.5 (W) x 44.5 (H) mm
